Parent Layer: Storm Abandoned (Brown)

Name: Storm Abandoned Main

Display Field: DECOMTYPE

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: <DIV STYLE="text-align:Left;"><DIV><DIV><P><SPAN>The decommissioned storm main is a pipe that no longer participates in the storm water network. Decommissioned storm mains are classified as either "Abandoned" (remains in the ground with the disconnected ends being capped) or "Removed" (removed from the ground). Types captured include: Gravity Main (Collector, Culvert, Box Culvert, Lateral (Standard, Lead, Wye). </SPAN></P><P><SPAN /></P><P><SPAN /></P></DIV></DIV></DIV>

Copyright Text:

Default Visibility: true

MaxRecordCount: 3000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 10000.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: true

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 468771.05495
YMin: 5365014.71103125
XMax: 480031.54676875
YMax: 5376105.761725
Spatial Reference: 3157  (3157)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: DECOMMAINTYPE
Field 2: N/A
Field 3: N/A
Field Delimiter: ,
Default Symbol:
N/A
Default Label: N/A
UniqueValueInfos:
• Value: dgmac
  Label: Gravity Main : Collector
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [255, 255, 190, 255]
  Width: 4
• Value: dgmbc
  Label: Gravity Main : Culvert
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [255, 255, 190, 255]
  Width: 4
• Value: dgmcb
  Label: Gravity Main : Box Culvert
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [255, 255, 190, 255]
  Width: 4
• Value: dllas
  Label: Lateral : Standard
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [255, 255, 190, 255]
  Width: 4
• Value: dllbl
  Label: Lateral : Lead
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [255, 255, 190, 255]
  Width: 4
• Value: dllcw
  Label: Lateral : Wye
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [255, 255, 190, 255]
  Width: 4
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• DECOMMAINTYPE ( type: esriFieldTypeString, alias: Main Type, length: 5 , Coded Values: [dgmac: Gravity Main : Collector] , [dgmbc: Gravity Main : Culvert] , [dgmcb: Gravity Main : Box Culvert] , ...3 more... )
• CROSSSECTIONSSHAPE ( type: esriFieldTypeString, alias: Cross Section Shape, length: 20 , Coded Values: [Circular: Circular] , [Arch: Arch] , [Box: Box] , ...1 more... )
• ADMINISTRATIVEAREA ( type: esriFieldTypeString, alias: Administrative Area, length: 4 , Coded Values: [BCH: BC Hydro] , [CRD: Capital Regional District] , [CS: District of Central Saanich] , ...11 more... )
• FACILITYID ( type: esriFieldTypeString, alias: Facility ID, length: 12 )
• MATERIAL ( type: esriFieldTypeString, alias: Material, length: 30 , Coded Values: [AC: Asbestos Cement] , [CI: Cast Iron] , [CL: Concrete Liner] , ...28 more... )
• DIAMETER ( type: esriFieldTypeSmallInteger, alias: Diameter (mm) , Coded Values: [-1: Other] , [0: Unknown] , [25: 25] , ...39 more... )
• SHAPE ( type: esriFieldTypeGeometry, alias: SHAPE )
• SHAPE.LEN ( type: esriFieldTypeDouble, alias: SHAPE.LEN )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
